Chapter 1: ML628 Board Features and Operation
Power Management
Numbers 1a through 1j refer to the callouts in Figure 1-2 :
1a : Main power switch (SW1)
1b : 12V Mini-Fit connector (J122)
1c : 12V ATX connector (J141)
1d : Power regulation jumpers (J30, J32, J61, J102, J104, J105, J129)
1e : Regulation inhibit (J289)
1f : External power supply jacks (J234, J440, J223, J174, J98, J175, J227, J173, J220)
1g : TI PMBus cable connector (J14)
1h : GTX transceiver power supply module
1i : GTH transceiver power supply module
1j : Active heatsink power connector
Board Power and Switch
The ML628 board is powered through J122 using the 12V AC adapter included with the
board. J122 is a 6-pin (2 x 3) right angle Mini-Fit type connector.
Caution! Do NOT plug a PC ATX power supply 6-pin connector into J122 on the ML628 board. The
ATX 6-pin connector has a different pinout than J122. Connecting an ATX 6-pin connector into J122
will damage the ML628 board and void the board warranty.
Power can also be provided through:
?
?
Connector J141 which accepts an ATX hard disk 4-pin power plug
Jack J234 which can be used to connect to a bench-top power supply
Caution! Do NOT apply power to J122 and connectors J141 and/or J2 3 4 at the same time.
Doing so will damage the ML628 board.
The ML628 board power is turned on or off by switch SW1. When the switch is in the ON
position, power is applied to the board and a green LED (DS36) illuminates.
10
www.xilinx.com
ML628 Board User Guide
UG771 (v1.1) February 19, 2014
